"Management features :
Reset button : Y
Power :
Power source type : PoE
Power consumption (typical) : 4.32 W
Power over Ethernet (PoE) : Y
Operational conditions :
Operating temperature (T-T) : -40 - 50 °C
Operating relative humidity (H-H) : 10 - 85%
System requirements :
Windows operating systems supported : Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 8,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64
Performance :
RoHS compliance : Y
Certification : CE, FCC, ONVIF, IP68, IK10, NEMA 4X
Type : IP security camera
Placement supported : Outdoor
Connectivity technology : Wired
PTZ control (Pan/Tilt/Zoom) : Y
Wide Dynamic Range (WDR) : Y
Day/night mode : Y
Design :
Form factor : Bullet
Mounting type : Wall
Product colour : Silver
LED indicators : Power
Protection features : Vandal-proof
International Protection (IP) code : IP68
IK code : IK10
Weatherproof : Y
Country of origin : Taiwan
Camera :
Camera shutter type : Electronic
Camera shutter speed : 1/5 - 1/10000 s
Minimum illumination : 0.1 lx
Viewing angle, horizontal : 70.5°
White balance : Auto
Image sensor :
Sensor type : CMOS
Progressive scan : Y
Optical sensor size : 25.4 / 3.2 mm (1 / 3.2"")
Lens system :
Number of lenses : 1
Zoom capability : Y
Focus : Manual
Focus adjustment : 1.4
Focal length range (f-f) : 2.8 - 12 mm
Night vision :
Night vision : Y
Night vision distance : 30 m
LED type : IR
Number of illumination LEDs : 15
Video :
Maximum resolution : 2048 x 1536 pixels
Total megapixels : 3 MP
Video formats supported : RAW
Video compression formats : H.264,M-JPEG
Supported graphics resolutions : 320 x 240,640 x 480 (VGA),1280 x 720 (HD 720),1920 x 1080 (HD 1080),2048 x 1536 (QXGA)
Supported video modes : 240p,480p,720p,1080p
Frame rate : 30 fps
Video streaming : Y
Noise reduction : Y
Automatic gain control : Y
Back Light Compensation (BLC) : Y
Image quality adjustment : Brightness,Contrast,Saturation,Sharpness
Full HD : Y
Audio :
Built-in microphone : N
Voice codecs : G.711
Networking :
Ethernet LAN : Y
Wi-Fi : N
Ethernet interface type : Fast Ethernet
Supported network protocols : TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour
Storage :
Built-in HDD : N
Card reader integrated : Y
Compatible memory cards : MicroSD (TransFlash),MicroSDHC,MicroSDXC
Maximum memory card size : 64 GB
Ports & interfaces :
Ethernet LAN (RJ-45) ports : 1
Microphone in : Y
Headphone outputs : 1
Terminal block port : Y
Interface : RJ-45
Weight & dimensions :
Package width : 285 mm
Package depth : 202 mm
Package height : 100 mm
Package weight : 414 g
Package type : Box
Width : 77 mm
Depth : 193 mm
Height : 73 mm
Weight : 955 g
Logistics data :
Master (outer) case width : 56.5 cm
Master (outer) case length : 41 cm
Master (outer) case height : 20.5 cm
Master (outer) case weight : 11.9 kg
Quantity per master (outer) case : 8 pc(s)
Technical details :
Iris : Y
Back light compensation method : Y
Number of video streams : 2
Packaging content :
Number of cameras : 1
Resource CD : Y
Wall mounting kit : Y
Quick installation guide : Y"
