DIGITAL SIGNAGE

The Avocor S Series is a part of our portfolio designed to elevate educational environments. combining sleek design with advanced touch technology. Ideal for classrooms. lecture halls. and hybrid learning settings. the S Series ensures every interaction is engaging and intuitive.

Ensure every educational session. whether in-person or remote. is seamless with the Avocor S Series. Its modern aesthetics and robust functionality make it the perfect solution for schools and universities seeking high performance. interactive displays.

Its diverse connectivity options support seamless integration with various educational tools and devices.
Preloaded with applications like Class. Note. Share. and Browse*. the S Series transforms standard lessons into interactive experiences. keeping students engaged and informed.

Display
Display diagonal: 2.18 m (86")
Display brightness: 350 cd/m²
Display number of colours: 1.07 billion colours
Display resolution: 3840 x 2160 pixels
Feature: Anti-glare screen
HD type: 4K Ultra HD
Feature: LED backlight
LED backlighting type: Direct-LED
Native aspect ratio: 16:9
Contrast ratio (typical): 5000:1
Maximum refresh rate: 60 Hz
Feature: Touchscreen
Touch technology: Multi-touch
Touchscreen type: Infrared
Number of simultaneous touchpoints: 40
Viewing angle. horizontal: 178°
Viewing angle. vertical: 178°
Feature: Pen & touch differentiation
Technology: Infrared (IR)
Computer system
Operating system installed: Android
Operating system version: 13
Feature: Built-in processor
Processor architecture: ARM Cortex A76 + ARM Cortex A55
Processor cores: 4
Maximum internal memory: 64 GB
RAM capacity: 8 GB
Graphics card family: ARM
Graphics card: Mali-G51 MP2
Audio
Feature: Built-in speaker(s)
Number of built-in speakers: 2
Speaker power: 32 W
Network
Feature: Wi-Fi
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Feature: Bluetooth
Feature: Ethernet LAN
Ports & interfaces
Feature: HDCP
HDCP version: 2.2
USB connector type: USB Type-A. USB Type-B. USB Type-C
USB 2.0 Type-A hub ports quantity: 4
USB 2.0 Type-B Touch ports quantity: 2
HDMI ports quantity: 3
USB Type-C ports quantity: 1
Feature: USB Type-C DisplayPort Alternate Mode
HDMI output ports quantity: 1
Feature: USB Power Delivery (USB PD)
USB Power Delivery up to: 65 W
Ethernet LAN (RJ-45) ports: 2
VGA (D-Sub) ports quantity: 1
Feature: Line-in
Feature: Line-out
OPS slot: 1
Feature: S/PDIF out port
RS-232 ports: 1
Ergonomics
Feature: VESA mounting
Panel mounting interface: 800 x 600 mm
Feature: Wall mountable
Performance
Feature: Ambient light sensor
Operating hours (hours/days): 16/7
Power
Power consumption (typical): 520 W
Power consumption (standby): 0.5 W
System requirements
Windows operating systems supported: Windows 10. Windows 11. Windows 8
Feature: Mac compatibility
Feature: Mac operating systems supported
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Width: 1957 mm
Depth: 100 mm
Height: 1160 mm
Weight: 58.5 kg
Packaging data
Package width: 2110 mm
Package depth: 225 mm
Package height: 1283 mm
Package weight: 72.7 kg
Packaging content
Feature: Pen tray included
Feature: Remote control included
Feature: Batteries included
Feature: Mounting brackets included
Feature: Stylus included
Stylus pen type: Passive
Number of stylus pens: 2
Other features
Warranty period: 3 year(s)
Country of origin: China
