Designed to support distances up to 550 metres. the DEM-431XT is a high performance 850nm Multi-Mode SFP+ transceiver. Supporting Full-duplex. 10 Gigabit speeds on Multi-Mode fibre cables. The DEM-431XT is 802.3ae 10GBASE-SR compliant and supports Full-duplex 802.3x Flow control. The DEM-431XT provides the necessary signal amplification for data to be transmitted to the network cable from the port. and vice versa.

D-Link’s 10G SFP+ Module series are hot-swappable SFP+ transceivers that plug into SFP+ slots on switches and support 10G Ethernet. The D-Link 10GBASE SFP+ Module Series transceivers offer customers a wide variety of 10G Ethernet connectivity options for data centers. enterprise wiring closets. and service provider transport applications.

Enhanced Small Form-factor Pluggable Format

The transceivers use the Enhanced Small Formfactor Pluggable format (SFP+). The SFP+ form factor is smaller than other form factors such as Xenpak. X2. and 10G XFP. ensuring lower costs. lower power disruption. and higher port density. They provide the necessary signal amplification for data to be transmitted to the network cable from the port. and vice versa. for the port to receive data from the network cable.

Hot Pluggable

All D-Link transceivers are hot-pluggable. You can connect a transceiver while the system is powered on without causing any problems. This permits modules to be added or removed without interrupting the network.

10G Ethernet speeds

The transceivers all support 10G Ethernet. which results in very fast data transmissions of up to 10 Gbit/s. This is 10 times faster than Gigabit Ethernet and enables the switch to handle faster and higher data transmissions. making it very suitable for business needs.

Performance
SFP transceiver type: Fiber optic
Maximum data transfer rate: 10000 Mbit/s
Interface type: SFP+
Feature: Multi-mode fiber (MMF) supported
Fiber optic connector: LC
Fiber cable diameters supported (core/cladding): 50/125.62.5/125 µm
SFP transceiver standard: SR
Maximum transfer distance: 550 m
Wavelength: 850 nm
Tx power (min): -6.5 dBmW
Tx power (max): -1 dBmW
Rx power (min): -11.1 dBmW
Rx power (max): -1 dBmW
Link budget: 10.1 dB
Networking standards: IEEE 802.3ae
Fiber ethernet cabling technology: 10GBASE
Duplex system: Full
Features
Product colour: Gold. Metallic
Feature: Hot-Plug support
Mean time between failures (MTBF): 3960000 h
Power
Maximum voltage: 3.3 V
Maximum current: 300 A
Certificates
Compliance certificates: RoHS
Safety: UL. TUV. CDRH
Certification: CE. FCC. VCCI. C-Tick. MSA
Operational conditions
Operating temperature (T-T): 0 - 70 °C
Storage temperature (T-T): -40 - 85 °C
Operating relative humidity (H-H): 5 - 85%
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Width: 14.8 mm
Depth: 11.8 mm
Height: 56.5 mm
Weight: 18 g
Packaging data
Package width: 74 mm
Package depth: 131 mm
Package height: 49 mm
Package weight: 64 g
Logistics data
Shipping (inner) case length: 36 cm
Shipping (inner) case width: 26 cm
Shipping (inner) case height: 31 cm
Shipping (inner) case net weight: 3.2 kg
Products per shipping (inner) case: 50 pc(s)
Pallet gross weight (air): 272 kg
Master (outer) cases per pallet (air): 60 pc(s)
Products per pallet (air): 3000 pc(s)
Pallet gross length: 102 cm
Pallet gross width: 122 cm
Pallet height (air): 199 cm
Pallet gross weight (sea): 272 kg
Master (outer) cases per pallet (sea): 60 pc(s)
Products per pallet (sea): 3000 pc(s)
Pallet height (sea): 199 cm
Shipping (inner) case gross weight: 4.2 kg
Harmonized System (HS) code: 85369010
